ASRock AMD Radeon RX 7700 XT Steel Legend 12GB OC
Видео карта ASRock AMD RADEON RX 7700 XT Steel Legend 12GB GDDR6, RX7700XT SL 12GO
Арт. номер: ASR-VC-RX7700XT-SL-12GO
Изчерпан
Запитване за ASRock AMD Radeon RX 7700 XT Steel Legend 12GB OC
безплатна доставка
на поръчки над 100 EUR
Технически характеристики
| Гаранция | 36 месеца |
| Памет | 12 GB |
| Ядра | 3456 Stream |
| Честота | 2276 MHz |
| Шина | 192 bit |
| Изходи | HDMI, DisplayPort |
| Тип на паметта | GDDR6 |
| Серия | RX 7000 Series |
Свързани продукти
Памет:
16 GB
Ядра:
2048 Stream
Честота:
2700 MHz
Шина:
128 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
2048 Stream
Честота:
2780 MHz
Шина:
128 bit
Изходи:
HDMI, DisplayPort
Памет:
12 GB
Ядра:
160 XMX
Честота:
2740 MHz
Шина:
192 bit
Изходи:
HDMI, DisplayPort
Памет:
12 GB
Ядра:
160 XMX
Честота:
2800 MHz
Шина:
192 bit
Изходи:
HDMI, DisplayPort
Памет:
8 GB
Ядра:
2048 Stream
Шина:
128 bit
Изходи:
HDMI, DisplayPort
Памет:
10 GB
Ядра:
144 XMX
Честота:
2600 MHz
Шина:
160 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
3584 Stream
Честота:
2070 MHz
Шина:
256 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
4096 Stream
Честота:
2400 MHz
Шина:
256 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
4096 Stream
Честота:
2400 MHz
Шина:
256 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
4096 Stream
Честота:
2400 MHz
Шина:
256 bit
Изходи:
HDMI, DisplayPort
Памет:
6 GB
Честота:
2250 MHz
Шина:
96 bit
Изходи:
HDMI, DisplayPort
Памет:
16 GB
Ядра:
4096 Stream
Честота:
2570 MHz
Шина:
256 bit
Изходи:
HDMI, DisplayPort
Видео карта ASRock AMD RADEON RX 7700 XT Steel Legend 12GB GDDR6
- Clock: GPU / Memory
Boost Clock*: Up to 2599 MHz / 18 Gbps
Game Clock**: 2276 MHz / 18 Gbps - Key Specification
AMD Radeon RX 7700 XT GPU
12GB GDDR6 on 192-Bit Memory Bus
54 AMD RDNA 3 Compute Units (with RT+AI Accelerators)
48MB AMD Infinity Cache technology
Microsoft DirectX 12 Ultimate
PCI Express 4.0 Support
2 x 8-pin Power Connectors
3 x DisplayPort 2.1***, 1 x HDMI 2.1 - Key Features
Polychrome SYNC
Triple Fan Design
Stylish Metal Backplate
Reinforced Metal Frame
Striped Axial Fan
Air Deflecting Fin
Ultra-fit Heatpipe
Polychrome SYNCCreate your own unique colorful light effects.With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
|
LED On/Off SwitchOn or Off? Switch as You Want.You can switch not only the built-in ARGB LEDs but also the ARGB LEDs equipping with the connected strips/devices at once.
|
Triple Fan DesignTriple fan design helps to optimize system cooling to reduce the operating temperature.
|
Stylish Metal BackplateSolid, Fancy, Cool.Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
|
Reinforced Metal FrameBe solid. No sag.Enhances the structure to prevent the PCB from being bent.
|
Striped Axial FanDesigned For Enhanced Airflow.ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.
|
|
0dB Silent CoolingSpin For Cooling, Stop For Silence.The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
|
Air Deflecting FinGuide Airflow to Go Through Regularly & Quickly.Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
|
Ultra-fit HeatpipeConsolidated to Maximize the Contact.The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
|
Nicked Plated Total Copper BaseOptimize GPU and VRAM thermal transfer.The large nickel-plated total copper base helps to optimize the thermal transfer for both GPU and VRAM effectively.
|
High-density Metal WeldingImprove Heat Dissipation.Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
|
Nano Thermal PastePerfect Thermal Teamwork.Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
|
Premium Thermal PadBetter Heat Transfer.The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
|
Precise Screw TorqueOptimized Mounting Pressure.ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
|
High Density Glass Fabric PCB |
Dr. MOS |
Premium 90A Power Choke |
 |
 |
 |
| High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity. | Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance. | Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card. |
2oz Copper PCB |
Matte Black PCB |
|
 |
 |
|
| Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking. | A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card. |
ASRock Tweak 2.0Pro and Easy-to-Use Tuning Utility.Provides the smart fan speed control and instant performance tweaking.
|
8K Resolution SupportNot only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
|
PCI Express 4.0 SupportThis graphics card features PCI Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI Express 3.0. Get ready for the next generation of PC gaming.
|
AMD Eyefinity TechnologyAMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
|
| Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort 2.1 technology. The Radeon RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K. |
GAMEThe AMD Radeon RX 7700 XT and 7800 XT graphics cards set a new level of performance for gamers. Featuring up to 16GB of GDDR6 memory, unified AMD RDNA 3 compute units, and next-generation features to enable ultra-fast, ultra-smooth gaming performance at 1440p, and the flexibility to experience ultra-detailed graphics at 4K. Immerse yourself even further with the AMD Radiance Display Engine and DisplayPort 2.1 to experience up to 68 billion colors for video playback and support for up to 8K.
|
STREAMGet ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders. With improved encoding performance and enhanced visual quality when streaming, the Radeon RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression5 featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
|
ADVANCECombine AMD Radeon RX 7700 XT and 7800 XT graphics cards with AMD Ryzen processors to activate AMD smart technologies. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon RX 7000 Series graphics cards with the AMD Software: Adrenalin Edition application, featuring bulletproof drivers, for the best PC gaming experiences.
|
UPSIZE PERFORMANCE.
|
Specifications
| Graphics Engine | AMD Radeon RX 7700 XT | Resolution | Digital Max Resolution: 7680 x 4320 |
| Bus Standard | PCI Express 4.0 x16 | Interface | 3 x DisplayPort 2.1* 1 x HDMI 2.1 *DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 4 ports simultaneously.
|
| DirectX | 12 Ultimate | HDCP | Yes |
| OpenGL | 4.6 | Multi-view | 4 |
| Memory | 12GB GDDR6 | Recommended PSU | 750W |
| Engine Clock | Boost Clock*: Up to 2599 MHz - Game Clock**: 2276 MHz *Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. |
Power Connector | 1 x 8-pin |
| Stream Processors | 3456 | Accessories | 1 x Quick Installation Guide |
| Memory Clock | 18 Gbps | Dimensions | 304 x 131 x 56 mm, 2.8-slot |
| Memory Interface | 192-bit | Net Weight | 1242 g |
